Asset Tracker 4G
Network/Operating Band
LTE FDD Cat M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19
/B20/B25/B26/B27/B28/B66/B85
LTE FDD Cat NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19
/B20/B25/B28/B66/B71/B85
GSM/EDGE: 850/900/1800/1900 MHz
Battery Life
4000mAh battery (1 report per day):
GPS on 3.3 years
GPS off: 4.5 years
GNSS Specifications
GNSS Chipset：All-In-One GNSS Receiver
Parallel GNSS：GPS + Glonass + Beidou + Galileo +QZSS
Horizontal Position Accuracy
Autonomous: < 1.5 m CEP
TTFF @ -130 dBm with (without) EPO：
Cold start: < 29s
Warm start: < 27s
Hot start: < 1s
Interfaces
Data Transmission：4 Pin port TypeC USB
Network, GNSS, WIFI Antenna：Internal only
Indicator LED：Network, GNSS
FOTA：Yes
Temperature Sensor：1
General Specifications
Waterproof：IP67
Dimensions：
82.8mm*66.9mm*35.7mm (3.26” *2.63” *1.40”)
Weight：160g (5.65oz)
Battery：Non-rechargeable 4000 mAh/3.0V battery (optional 8000 mAh)
Data Communication: TypeC USB cable
Operating Temperature：-30℃ ~ 80℃ (-22°F ~176°F)
Air Interface Protocol
Transmit Protocol：TCP, UDP, MQTT, SMS
Data Security & Encryption Option: MD5/AES
Geo-fence：Support up to 64 internal geo-fence regions
Low Power Alarm：Sending alarm when battery is low
